ABP 60 Nilang Asphalt Batch Mix Plant

Batch Size

750 kg

Brand

Nilang

Weighing Unit Filler Hopper

150 kg

Weighing Unit Bitumen Hopper Capacity

175 kg

Weighing Unit Aggregate Hopper Capacity

1000 kg

Thermo Drum Dryer (L x D)

6 x 1.2 mtrs

Thermic Oil Heater Heating System Hot Oil Heater Capacity

Direct Kcal/hr

Secondary Filter Area

180 m2

Secondary Bag House Filter

Bag House Filter Reverse Air Flow

Screening Unit Screening Method Inclined Linear vibration No.of Deck

2 Deck

Screening Unit Screening Capacity

80 TPH

Primary Type

Centrifugal Cyclonic Pre Separator

Plant Capacity@3% Moisture Content

60 TPH

Model No

ABP 60

Mixer Unit Mixer Capacity

750 Kg

Mixer Unit Bitumen Pump

350 LPM

Hot Mix Storage Silo Capacity Range (Optional)

10 Ton

Hot Elevator Capacity

80 TPH

Hot Aggregate Bin Unit No.of Bins

4 Bins

Filler Silo Capacity Range

2 m3

Filler Screw Capacity

10 tph

Cycle Time

45 sec

Control Panel Type

Siemens PLC ( SCADA on Request )

Cold Feed Bins Capacity

20 m3

Cold Feed Bins

4 Bins

Charging Conveyor Capacity

80 TPH

Burner Type

High Pressure, Fully Automatic, Modulating

Burner Fuel

Diesel, LDO, Furnace Oil

Burner Driver Type

4 W Friction Drive

Burner Capacity

6 Mw

Bitumen Tank Capacity Range Direct / Thermic Oil Heating

20 Ton
